PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

Dongguan Bright Packaging Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

Brand Name : Bright Pack

Model Number : B010

Certification : patent for invention、BRC、GRS

Place of Origin : Guangdong,China

MOQ : 100pcs

Price : $3-3.5/kg

Payment Terms : T/T,Western Union

Supply Ability : 200000pcs/day

Delivery Time : 11-13work days

Packaging Details : Export special carton packaging and plate

Customization : Support

Colour : Up To 10 Colour Or No Printed

Odor Proof : Yes

Custom Order : YES.

Colors : CMYK/Pantone

Sample : Free

Puncture Resistant : Yes

Packaging Type : Bulk Pack

Quantity Per Pack : 100

Recyclable : Yes

Quantity : Pack of 100 bags

Bag Type : Three side seal stand up bag

Bpa Free : Yes

Color : Transparent

Height : 115 MM

Contact Now

Product Attributes

Attribute Description
Material Structure Trilayer composite: ​PET outer​ (mechanical strength/UV blocking), ​Aluminum middle​ (oxygen/moisture barrier), ​PE inner​ (heat-sealable & chemical-resistant)
Primary Function Ensures chemical stability of ClO₂ disinfectant by blocking light/oxygen/moisture; prevents gas leakage and decomposition
1
6
Barrier Technology Aluminum foil (7–12 µm) reduces OTR to ​​≤0.05 cm³/m²/day​ (ASTM F1249) + PET layer blocks 99% UV light to inhibit ClO₂ photolysis
1
6
Seal Integrity PE inner layer enables strong heat seals (≥25 N/15mm); compatible with ultrasonic sealing to avoid ClO₂ thermal degradation (>80°C)
4
9
Surface Treatment Anti-static coating (≤10⁹ Ω/sq) prevents dust adsorption during high-speed filling; lightproof black/amber PET variants available
1
5
Chemical Stability Neutral pH (6.5–7.5) and inert layers prevent reactions with ClO₂; maintains ≥95% active ingredient efficacy for 12 months
11
13
Certifications Complies with ​FDA 21 CFR, ​ISO 22000​ for indirect food contact; EPA-registered for disinfectant packaging
8
10
Sustainability Recyclable PET/AL/PE structure; biodegradable PLA/PE alternatives available (EN13432 certified)
6
7

Product Specifications

Parameter Specification Test Standard
Thickness 80–200 µm (customizable; 120 µm standard for heavy-duty use) ISO 4593
OTR (Oxygen Transmission Rate)​ ≤0.05 cm³/m²/day ASTM F1249
WVTR (Water Vapor Transmission Rate)​ ≤0.5 g/m²/day ASTM D3985
Light Transmittance <0.5% (UV-Vis range, 200–400nm) ASTM D1003
Puncture Resistance ≥35 N (protects against sharp disinfectant crystals) ASTM D7192
Seal Strength ≥25 N/15mm (heat seal), ≥20 N/15mm (ultrasonic cold seal) ASTM F88
Thermal Stability -40°C to 100°C (withstands freezing/boiling; ClO₂ decomposition threshold: >80°C)
4
13
ASTM D882
Surface Resistance 10⁸–10¹¹ Ω/sq (anti-static)
1
ASTM D257
Roll Dimensions - ​Width: 200–1,200 mm
- ​Length: 1,000–10,000 m
- ​Core ID: 76 mm (3") or 152 mm (6")
N/A
MOQ & Logistics - ​MOQ: 500 kg
- ​Lead Time: 15–25 days
- ​Packaging: Moisture-proof wooden pallets

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability
